Factory For Cds Polycrystal 99.999% - Cadmium Sulfide – WMC

Selenium  is amorphous gray  metallic luster solid material, which is becoming black on standing and crystalline on heating, soluble in concentrated nitric acid and in common alkali, lower toxicity. Selenium can burn in air and sent out blue flame, generate two selenium oxides, has also reaction with metal or non-metal directly including hydrogen and halogen.

High purity selenium or high purity oxygen free selenium of 99.999 and 99.9999% 5N 6N purity by the purification process of rectification is primarily used in the preparation of compound semiconductor materials such as Antimony Selenide Sb2Se3, Arsenic Selenide As2Se3, Cadmium Selenide CdSe, Copper Selenide CuSe, Molybdenum Selenide MoSe2, Tin Selenide SnSe Tungsten Selenide WSe2, Zinc Selenide ZnSe and Selenide Sulfide SeS2 etc, selenium drum, photoconductive and photovoltaic material, electrostatic photograph, infrared glass, and other materials for optical devices and instruments.  High Purity Selenium at Western Minmetals (SC) Corporation with 99.999%, 99.9999% 5N 6N purity with oxygen free can be delivered in form of  powder, granule and lump or as customized specification.


Details

Tags

CdS-W3

No.

Items

Standard Specifications

1

Poly-Crystalline Cadmium Sulfide CdS Purity

 5N 99.999% Min

Impurity Max

Mg/Fe/Ni/Cu/Al/ Ca/Sn/Pb/Bi/Zn 1.0 ppm each

Cr/Sb/Ag 0.5ppm each

Size

-60/-80mesh, 1-20mm lump

2

Single Crystal Cadmium Sulfide CdS Shape

 Substrate

 Blank

Size

Substrate D50.8mm

Square 10x10mm

Conductivity

N/P-doped or Semi-insulating

N/P-doped or Semi-insulating

Orientation

<001>

<001>

Thickness

500±15μm

(250-300)±10

Resistivity

<5Ω-cm

<5 or >106Ω-cm

Infrared Transmittance

>71%

>71%

Hall Mobility

2×10-2 cm2/V.s

2×10-2 cm2/V.s

3

Packing

Single wafer container inside, carton box outside.

  • Sample Available Upon Request
  • Safety Delivery of Goods By Courier/Air/Sea
  • COA/COC Quality Management
  • Secure & Convenient Packing
  • UN Standard Packing Available Upon Request
  • Quality Inspection Including XRD/SEM/ICP/GDMS etc
  • Full Scope of Trade Terms CPT/FOB/ CFR/CIP By Incoterms 2010
  • Flexible Payment Terms T/T D/P L/C Acceptable
  • Full Dimensional After-Sale Services
  • ISO9001:2015 Certified & Rohs/REACH Regulations Approval
  • Non-Disclosure Agreements
  • Non-Conflict Mineral Policy
  • Regular Environmental Management Review
  • Social Responsibility Fulfillment
